Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 220 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 12.5 mm |
| Mount Hole Diameter (C.2) | 12.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 15 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | POONGSUNG |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DOOSAN | D15S-5 | [A2300] | 01.2007-12.2016 |
| DOOSAN | D18S-5 | [A2300] | 01.2007-12.2016 |
| DOOSAN | D20S-5 | [A2300] | 01.2007-12.2016 |
| DOOSAN | D20SC-5 | [A2300] | 01.2007-12.2016 |
Reference Information
CGB-23180 690.525.152.050 91-33-1001 DS1347 20428601BN 88215030 6041106 STR85400 20428601OE 246-20127 31013180 DRS0237 STR6664 CST41106GS 8305 254329 CST41106AS STY0001 LRS3955 190-20320 690.525.152.360 690.525.152.362 UD21256S 690.525.152.265 690.525.152.620 115968 4900574 336544 6041106.1 19188N 25-5117 LRS03955Video/Publications
031013180 UD21256S STR85400 4900574 91-33-1001 690.525.152.620 690.525.152.050 690.525.152.362 CST41106AS CST41106GS 20428601BN 20428601OE 6041106.0 6041106.1 254329 8305 25-5117 115968 LRS03955 LRS3955 88215030 DRS0237 DS1347 19188N 190-20320 STY0001 246-20127 CGB-23180 690.525.152.265 690.525.152.360Add Your Number
