Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 351 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 32 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | Engine 4.4 | [T] | |
CATERPILLAR | Engine 4.4 | [TA] | |
CATERPILLAR | Engine 4.4 | [TTA] | |
CATERPILLAR | Engine 7.1 | [TA] |
Reference Information
TS-6273 STI4838 T411405 AZF4838 STR7869 641.525.103.311 MAHMS447 6021625.1 AZF4801 11.132.186 UD812163(LETRIKA)S 11.131.889 CST21625GS MS447 20419526OE 3825901 72736075 3417602 641.525.103.090 182-30459 255190M IS1295Video/Publications
11.131.889 MAHMS447 UD812163(LETRIKA)S IS1295 11.132.186 AZF4801 AZF4838 72736075 3417602 3825901 T411405 255190M 641.525.103.311 641.525.103.090 182-30459 STI4838 TS-6273Add Your Number
