Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 99 mm |
Mount Hole Diameter (C.1) | 15.5 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 23 mm |
Rotation | CW |
Spigot Diameter (A) | 71 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Dakota 3.7 | 01.2004-12.2008 | |
DODGE | Dakota 3.9 | 01.1999-12.2003 | |
DODGE | Dakota 4.7 | 01.2000-12.2008 | |
DODGE | Dakota 5.2 | 01.1999-12.1999 | |
DODGE | Dakota 5.9 | 01.1999-12.2003 | |
DODGE | Durango 3.9 | 01.1999-12.1999 | |
DODGE | Durango 5.2 | 01.1999-12.2000 | |
DODGE | Durango 5.9 | 01.1999-12.2003 | |
DODGE | Ram 1500 3.7 | 01.2002-12.2008 | |
DODGE | Ram 1500 3.9 | 01.1999-12.2002 | |
DODGE | Ram 1500 4.7 | 01.2002-12.2008 | |
DODGE | Ram 1500 5.2 | 01.1999-12.2001 | |
DODGE | Ram 1500 5.9 | 01.1999-12.2003 | |
DODGE | Ram 1500 Van 3.9 | 01.1999-12.2003 | |
DODGE | Ram 1500 Van 5.2 | 01.1999-12.2003 | |
DODGE | Ram 1500 Van 5.9 | 01.1999-12.2003 | |
DODGE | Ram 2500 5.2 | 01.1999-12.2001 | |
DODGE | Ram 2500 5.9 | 01.1999-12.2002 | |
DODGE | Ram 2500 Van 3.9 | 01.2001-12.2001 | |
DODGE | Ram 2500 Van 5.2 | 01.1999-12.2003 | |
DODGE | Ram 2500 Van 5.9 | 01.1999-12.2003 | |
DODGE | Ram 3500 5.9 | 01.1999-12.2002 | |
DODGE | Ram 3500 Van 5.2 | 01.1999-12.2001 | |
DODGE | Ram 3500 Van 5.2 | 01.2002-12.2003 | |
DODGE | Ram 3500 Van 5.9 | 01.1999-12.2003 | |
DODGE | Ram 4000 5.9 | 01.1999-12.2001 | |
DODGE | Ramcharger 5.2 | 01.1999-12.1999 | |
DODGE | Ramcharger 5.2 | 01.2001-12.2001 | |
DODGE | Ramcharger 5.9 | 01.1999-12.2001 | |
MITSUBISHI | Raider 3.7 | 01.2006-12.2009 | |
MITSUBISHI | Raider 4.7 | 01.2007-12.2007 |
Reference Information
UD21112S 228000-7421 5602-7702-AC 228000-7420 5602-7702-AB 5602-7702-AE 336-1722 5602-7702-AD STR6308 91-29-5444N SX3780 3371110 113120 CST40340AS S-8751 91-29-5444 STR70180 3755259 R602-7702-AC 830.556.102.050 PRSE227 60403400 STN3120 246-15125 17785R STRE227 17785N 5602-7702-AC2 5602-8210Video/Publications
17785N PRSE227 STRE227 336-1722 3371110 113120 CST40340 5602-7702-AB 5602-7702-AC 5602-7702-AC2 5602-7702-AD 5602-7702-AE 5602-8210 R602-7702-AC SX3780 228000-7420 228000-7421 S-8751 246-15125 830.556.102.050 STN3120 17785R 91-29-5444 91-29-5444N STR70180 UD21112S CST40340AS 60403400Add Your Number
