Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 205 mm |
Mount Hole Center - Center (O.1) | 108 mm |
Mount Hole Center - Center (O.2) | 73 mm |
Mount Hole Center - Center (O.3) | 75 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | 6.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 11.5 mm |
Rotation | CW |
Spigot Diameter (A) | 64 mm |
Unit Type | FORD |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TATA | Sumo Victa 2.0 DI | 01.2004-12.2007 |
Reference Information
7FBU-11000-AA 6014126.1 UD19658S 20450621OE CST14126GS 20-100-01056Video/Publications
7FBU-11000-AA UD19658S 20-100-01056 CST14126GS 20450621OE 6014126.1Add Your Number
