Specifications
Kilowatt | 7 kW |
Length (L.1) | 348 mm |
Mount Hole Center - Center (O.1) | 156 mm |
Mount Hole Center - Center (O.2) | 167 mm |
Mount Hole Center - Center (O.3) | 138 mm |
Mount Hole Diameter (C.1) | 15.5 mm |
Mount Hole Diameter (C.2) | 15.5 mm |
Mount Hole Diameter (C.3) | 15.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 54.5 mm |
Rotation | CW |
Spigot Diameter (A) | 122 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Engine |
Reference Information
STM2578 UD19578S 1811004211 20437117BN 256203M M009T82071 1811004210 130-90149 M9T82071 6035711 CST35711ASVideo/Publications
M009T82071 M9T82071 UD19578S 256203M CST35711AS 20437117BN 6035711.0 130-90149 STM2578 1811004211Add Your Number
