Specifications
| Amp | 11 A |
| Diameter (D.1) | 8 mm |
| Diameter (D.3) | 10 mm |
| Front Mount Thickness | 11 mm |
| Kilowatt | 0.9 kW |
| Length (L.1) | 238 mm |
| Mount Inside Length or Pad Mount C-C (C) | 150 mm |
| Pulley Type | n/a |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BCS | 601 0.3 | [ALN330WB] | 04.1985-04.2005 |
| BCS | 602 0.3 | [ALN330WB] | 04.1980-04.2005 |
| BCS | 604 0.3 | [IM350] | 04.1985-04.2000 |
| BCS | 715 0.3 | [ALN330WB] | 12.1978-12.1993 |
| BCS | 725 0.3 | [ALN330WB] | 12.1978-12.1993 |
| FERRARI | 90 0.3 | [ACME-AL290] | 06.1980-05.1985 |
Reference Information
39129201EL 1162558 39129201IT DIN241020 10350102 10350005 PRSF130 701012 4022102.3 DIN241020EL 6030 4022102.5 19025602 S0889S 6.0572E+11 5322001 DIN241020I 861096 670.001.011.650 DST10004 39129201BN DIN241020A CDS22102AS GEN1007 00010300101 D12EF0002A2 00010300003 CDS22102IS 4022102 CDS22102ES STB5235 10300101 10300003 STRF130 UD19592S 00010350102 110061 670.001.011.070 00010350005Video/Publications
0010300003 0010300101 110061 19025602 DST10004 UD19592S 701012 670.001.011.650 670.001.011.070 CDS22102AS CDS22102ES CDS22102IS 861096 39129201BN 39129201EL 39129201IT 4022102.0 4022102.3 4022102.5 PRSF130 STRF130 DIN241020 DIN241020A DIN241020EL DIN241020I STB5235 0010350005 0010350102 06030 1162558 605720110001Add Your Number
