Brand new AS-PL Alternator
STANDARD LINE
AS-PL
FORD
Price:
NZ$ 343.99 including GST
NZ$ 299.12 excluding GST
or four payments of $86.00
with
Learn More
each
A9355S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 130 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 13 mm |
| Length (L.1) | 133 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 55.50 mm |
| Pad mount thickness (E.2) | 55.50 mm |
| Plug Code | PL_3101 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 59 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | Solid |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Explorer 4.0 | 01.1997-01.1998 | |
| FORD | Explorer 4.0 | 01.1999-01.2002 | |
| FORD | Explorer 4.0 | 01.2002-01.2002 | |
| FORD | Explorer 4.0 | 01.2003- | |
| FORD | Explorer 4.0 | 01.2003-01.2003 | |
| FORD | Explorer 4.0 Sport | 01.2001-01.2002 | |
| FORD | Explorer 4.0 Sport | 01.2003-01.2003 | |
| FORD | Explorer 4.0 Sport Trac | 01.2001-01.2002 | |
| FORD | Explorer 4.0 Sport Trac | 01.2003-01.2003 | |
| FORD | Explorer 4.0 V6 4x4 | 10.1996-12.2001 | |
| FORD | Explorer 5.0 | 01.1996-01.1998 | |
| FORD | Explorer 5.0 | 01.1999-01.2001 | |
| MERCURY | Mountaineer 4.0 | 01.1998-01.2002 | |
| MERCURY | Mountaineer 4.0 | 01.2002-01.2002 | |
| MERCURY | Mountaineer 4.0 | 01.2003-01.2003 | |
| MERCURY | Mountaineer 5.0 | 01.1997-01.1998 | |
| MERCURY | Mountaineer 5.0 | 01.1999-01.2001 |
Reference Information
| 0986AN0669 | BOSCH |
| 0986CN0482 | BOSCH |
| 0986CR0482 | BOSCH |
| 0986UN0085 | BOSCH |
| 0986UN0482 | BOSCH |
| 0986UR0482 | BOSCH |
| 112946 | CARGO |
| 1L22-10300-AB | FORD |
| 1L2U-10300-AA | FORD |
| 1L2U-10300-AB | FORD |
| 1L2UAA | FORD |
| 1L2UAB | FORD |
| 1L2Z-10346-AA | FORD |
| 1L2Z-10346-AARM | FORD |
| 1L2Z-10346-AB | FORD |
| 1L2Z-10346-ABRM | FORD |
| 1L2Z10346ADRM | FORD |
| 1L2Z-10V346-ADRM | FORD |
| 1L2ZAB | FORD |
| 2014125.0 | SANDO |
| 20150521BN | REAL |
| 4G7U-10300-AA | FORD |
| 555119RI | KUHNER |
| 6C2T-10300-EB | FORD |
| 7787604 | DIXIE |
| 7787604N | DIXIE |
| 7787N-6G1 | WAI / TRANSPO |
| 7787N-6G2 | WAI / TRANSPO |
| 885.523.130.030 | PSH |
| 90-02-5086N | WILSON |
| A-272 | DIXIE |
| AL392N | BOSCH |
| AL7543N | BOSCH |
| AL7543X | BOSCH |
| ALF2946 | KRAUF |
| ALT42408 | WOODAUTO |
| ALT8010 | ELECTROLOG |
| CAL14125AS | CASCO |
| F032112946 | CARGO |
| F042304076 | BOSCH |
| F77U-10300-AB | FORD |
| F77U-10300-AC | FORD |
| F77U-10300-AD | FORD |
| F77Z-10346-AB | FORD |
| GL363 | FORD |
| GL423 | FORD |
| GL423RM | FORD |
| UD21093A | AS-PL |
| XL2U-10300-AA | FORD |
| XL2Z10346AA | FORD |
