Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 218 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 80 mm |
Mount Hole Center - Center (O.3) | 80 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 27.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | PRESTOLITE |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Cortina | ||
FORD | Escort 1.1 | 12.1974-12.1985 | |
FORD | Escort 1.3 | 12.1974-08.1980 | |
FORD | Sapphire | ||
FORD | Sierra 2.0 |
Reference Information
66925192 STR4099 EL25192 UD19360S 590.020.103.000Video/Publications
UD19360S 590.020.103.000 66925192 EL25192Add Your Number
