Specifications
| Kilowatt | 3 kW |
| Length (L.1) | 251 mm |
| Mount Hole Center - Center (O.1) | 79 mm |
| Mount Hole Center - Center (O.2) | 80 mm |
| Mount Hole Center - Center (O.3) | 133 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | M12x1.75 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 47.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | E-350 6.0 | [363ci] | 01.2004-12.2010 |
| FORD | E-450 6.0 | [363ci] | 01.2004-12.2010 |
| FORD | Excursion 6.0 | [363ci] | 01.2003-12.2005 |
| FORD | F-250 6.0 | [363ci] | 01.2003-12.2007 |
| FORD | F-350 6.0 | [363ci] | 01.2003-12.2007 |
| FORD | F-450 6.0 | [363ci] | 01.2003-12.2007 |
| FORD | F-550 6.0 | [363ci] | 01.2003-12.2007 |
Reference Information
3C3Z-11002-AA STF3703 91-02-5903 6670N 6670S S-2124 6670SN 590.570.123.020 91-02-5903N 6C2Z-11V00-2ARM1 6C2Z-11002-A STR89010 3C3U-11000-AA 3C3U-11000-AB 3C3U-11000-AC 3C3UAC 3C3UAB 3C3Z-11002-A 113703 6C2T-11000-AA 6C2TAA 6C2Z-11002-AA UD21113S 6C2T11000A 3C3Z-11002-AARM RM7U-2J11A-230BAVideo/Publications
6670N UD21113S 590.570.123.020 113703 STF3703 3C3U-11000-AA 3C3U-11000-AB 3C3U-11000-AC 3C3UAB 3C3UAC 3C3Z-11002-A 3C3Z-11002-AA 3C3Z-11002-AARM 6C2T-11000-AA 6C2TAA 6C2Z-11002-A 6C2Z-11002-AA 6C2Z-11V00-2ARM1 RM7U-2J11A-230BA S-2124 6670S 6670SN 91-02-5903 91-02-5903NAdd Your Number
