Specifications
Kilowatt | 2 kW |
Length (L.1) | 247 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | M12x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 14 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JUNGHEINRICH | Various Models | ||
STILL | Various Models |
Reference Information
CST40564GS 20432465OE 068911024R 300.956.122.260 DENDSN2103 300.956.122.261 DSN2103 UD810297(DENSO)S 438000-0972 438000-0971 MAV425640 438000-0970 6040564.1 STB1629 438080-0972Video/Publications
068911024R 438000-0970 438000-0971 438000-0972 438080-0972 DSN2103 UD810297(DENSO)S DENDSN2103 CST40564GS 20432465OE 6040564.1 300.956.122.261 300.956.122.260 MAV425640 STB1629Add Your Number
