Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 230 mm |
| Mount Hole Center - Center (O.1) | 91 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 26.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | GX 460 4.6 | [1UR-FE] | 01.2009-12.2010 |
| TOYOTA | Land Cruiser 4.6 V8 | [1UR-FE] | 01.2010-12.2012 |
Reference Information
SR3312X 000SR3312X 6E+11 6040400.1 19217N 28100-0S021 28100-38070 428080-8711 255523D 28100-38050 DSN1236 428000-6501 S-80527 STRJ088 UD16949S 428000-6502 190.921.092.260 STR6282 0986UR1794 DS2267 0000986CR1794 PRSJ088 STN3807 0000986UR1794 CST40400GS 91-29-5807 428000-8710 428000-6830 428000-6831 428000-8711 0986CR1794 428000-9101 J5212162 DRS1157 190.921.092.050 19217Video/Publications
428000-6501 19217 19217N 255523D 28100-38050 28100-38070 428000-6502 428000-6831 428000-9101 428080-8711 91-29-5807 DSN1236 J5212162 S-80527 STN3807 UD16949S PRSJ088 STRJ088 190.921.092.050 190.921.092.260 0986CR1794 0986UR1794 SR3312X CST40400GS 428000-6830 428000-8710 428000-8711 600000170260 DRS1157 DS2267 6040400.1 28100-0S021Add Your Number
