Associated Numbers
SNV023
0001157007 Bosch show
0001157015 Bosch show
0001157023 Bosch show
104271 FARC
11090056 EuroTec
111334 Cargo
11574 EAI
12411243181 BMW
12411244553 BMW
12411244606 BMW
1241124466 BMW
12411244670 BMW
12411244678 BMW
12411350246 BMW
12411357500 BMW
12419062425 BMW
184550 Valeo
18903 Lester
18904 Lester
210522092 PSH
252473 Elstock
432586 Valeo
4556SP Spidan
615004092 DRI
726137 Valeo
8080063 Friesen
8080063F Friesen
8EA737504001 Hella
91203538 Wilson
A74280 ATL
CS1106 HC
D6RA15 Valeo show
D6RA15SEL +line
D6RA7 Valeo show
LRS01510 Lucas
LRS1510 Lucas
SP4556 Spidan
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 212 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 27 mm |
| Rotation | CW |
| Spigot Diameter (A) | 62 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | R100 1.0 | 06.1976- | |
| BMW | R45 0.5 | 06.1978-07.1985 | |
| BMW | R50 0.5 | 07.1973- | |
| BMW | R60.5 0.6 | 06.1973- | |
| BMW | R60.6 0.6 | 09.1974-06.1978 | |
| BMW | R60.7 0.6 | 09.1976-06.1980 | |
| BMW | R65 0.7 | 06.1978-12.1993 | |
| BMW | R75.5 0.8 | 09.1980- | |
| BMW | R75.6 0.8 | 09.1973-08.1976 | |
| BMW | R75.7 0.8 | 09.1976-08.1979 | |
| BMW | R80 0.8 | 09.1977- | |
| BMW | R90 0.9 | 08.1973- |
Reference Information
12411350246 STR33002 12411244553 5015845 12411244670 STR0088 331258 270-12108 SR5050N 12411244678 25-2473 12411243181 S3006S 101106 8EA737504-001 210.522.092.000 CGB-52473 CST15175AS 432586 12411357500 D6RA15 71-20-18915 18915N SG0586 S12VA0236A2 91-20-3538 AI-80175 12419062425 LRS1510 210.522.092.770 6015175.1 111334 PRSS262 EAA-121318 UD19440S 20479571OE VAL432586 S12VA0236 12411244606 20479571BN CST15175GS STRS262 CS1106 210.522.092.501 D6RA7 210.522.092.500 LRS01510 101106V STV1106 6015175 11574 455632Video/Publications
25-2473 CS1106 D6RA15 D6RA7 UD19440S STR33002 VAL432586 71-20-18915 91-20-3538 101106 101106V 210.522.092.500 210.522.092.000 210.522.092.770 210.522.092.501 CST15175AS CST15175GS 11574 111334 LRS01510 LRS1510 20479571BN 20479571OE 6015175.0 6015175.1 18915N 12411244606 12411244670 STV1106 SG0586 270-12108 CGB-52473 AI-80175 455632 12411243181 12411244553 12411244678 12411350246 12411357500 12419062425 PRSS262 STRS262 SR5050N EAA-121318 8EA737504-001Add Your Number
