Specifications
Kilowatt | 0.5 kW |
Length (L.1) | 185 mm |
Mount Hole Center - Center (O.1) | 67 mm |
Mount Hole Diameter (C.1) | 8 mm |
Mount Hole Diameter (C.2) | 8 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 38.5 mm |
Rotation | ACW |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | Lawn X300 | ||
JOHN DEERE | Lawn X300R | ||
JOHN DEERE | Lawn X304 | ||
KAWASAKI | Engine | [FH381V] | |
KAWASAKI | Engine | [FH430V] | |
KAWASAKI | Engine | [FH480V] |
Reference Information
RS41058 71-09-5922 21163-7031 2830022060 STR88254 2810022060 MIU11006 114888 20415731BN 255359 S1259S MIA11564 CST38137AS 2.81002E+11 400.524.102.030 21163-7007 2810022071 106-10121 5922N 281002206171F 3004568 2810020060 2810022061 6038137 8758 UD19441SVideo/Publications
114888 21163-7007 MIA11564 MIU11006 RS41058 STR88254 21163-7031 71-09-5922 8758 5922N 106-10121 400.524.102.030 UD19441S 255359Add Your Number
