Specifications
Kilowatt | 1.5 kW |
Length (L.1) | 218 mm |
Mount Hole Center - Center (O.1) | 82 mm |
Mount Hole Diameter (C.1) | 10 mm |
Mount Hole Diameter (C.2) | 10 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 4 mm |
Rotation | CW |
Spigot Diameter (A) | 68 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BUICK | Allure 3.8 V6 | [231] | 01.2006-12.2009 |
BUICK | Lacrosse 3.8 V6 | [231] | 01.2006-12.2009 |
BUICK | Lucerne 3.8 V6 | [231] | 01.2006-12.2008 |
PONTIAC | Bonneville 3.8 V6 | [231] | 01.2004-12.2005 |
PONTIAC | Grand Prix 3.8 V6 | [231] | 01.2004-12.2005 |
PONTIAC | Grand Prix 3.8 V6 | [231] | 01.2006-12.2008 |
Reference Information
STR2217 UD19291S 9000857 6484N 255001 3231627 112903 3231437 9000930 9000872 91-01-4501 8000059 91-01-4501N 12563718 89017715 STD2903Video/Publications
112903 12563718 255001 3231437 3231627 8000059 89017715 9000857 9000872 9000930 91-01-4501 91-01-4501N STD2903 UD19291SAdd Your Number
