Specifications
| Kilowatt | 6 kW |
| Length (L.1) | 326 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 47.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 110 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAF | 85.360 12.9 | [MX265] | 10.2006-05.2013 |
| DAF | 85.410 12.9 | [MX300] | 10.2005-05.2013 |
| DAF | 85.460 12.9 | [MX340] | 10.2005-05.2013 |
| DAF | 85.510 12.9 | [MX375] | 10.2005-05.2013 |
| DAF | CF 85.360 12.9 | [MX-13265] | 10.2006- |
| DAF | CF 85.360 12.9 | [MX265] | 10.2006- |
| DAF | CF 85360 12.9 | [MX265] | 10.2006- |
| DAF | CF 85.410 12.9 | [MX-13303] | 10.2006- |
| DAF | CF 85.410 12.9 | [MX300] | 10.2005- |
| DAF | CF 85.410 12.9 | [MX300] | 10.2006- |
| DAF | CF 85410 12.9 | [MX300] | 10.2005- |
| DAF | CF 85410 12.9 | [MX300] | 10.2006- |
| DAF | CF 85.460 12.9 | [MX-13340] | 10.2006- |
| DAF | CF 85.460 12.9 | [MX340] | 10.2005- |
| DAF | CF 85.460 12.9 | [MX340] | 10.2006- |
| DAF | CF 85460 12.9 | [MX340] | 10.2006- |
| DAF | CF 85.510 12.9 | [MX-13375] | 10.2006- |
| DAF | CF 85.510 12.9 | [MX375] | 10.2005- |
| DAF | CF 85.510 12.9 | [MX375] | 10.2006- |
| DAF | CF 85510 12.9 | [MX375] | 10.2005- |
| DAF | FA 85.360 12.9 | [MX265] | 10.2006- |
| DAF | XF 105.410 12.9 | [MX300] | 10.2005- |
| DAF | XF 105.460 12.9 | [MX340] | 10.2005- |
| DAF | XF 105.510 12.9 | [MX375] | 09.2013- |
| DAF | XF 105.510 12.9 | [MX375] | 10.2005- |
| DAF | XF 95.380 12.6 | [XE280C] | 12.2005- |
| DAF | XF 95.430 12.6 | [XE315C] | 12.2005- |
Reference Information
1876369R STR10200 BOS0001261085 MAV126080A STD1418R 2015153 20401806RC 1956090 6010608 CST10608RS 2134698 901.515.123.210 1688625 CST10608GS 1667425 CST10608AS 1739935 1826121 1261086 0001261069 1261085 20401806OE 1261069 0001261086 0001261085 6.7049.1 20401806BN 220821 1876369 6010608.2 901.504.123.384 6010608.1 901.504.123.383 1843852 UD19233S S0882SVideo/Publications
6.7049.1 901.515.123.210 901.504.123.384 901.504.123.383 BOS0001261085 UD19233S 2134698 0001261086 0001261069 2015153 220821Add Your Number
