Associated Numbers
lr1100-712
lr1100712 231000w401 23100ow401
- LR1100-704, LR1100-704B, LR1100-716, LR1100-716C, LR1100-716CAM, LR1100-716CR
- J&N ELECTRICAL PRODUCTS 400-44037
- LESTER 13724
- LUCAS ELECTRIC LRA02329
- NISSAN 23100-0W400, 23100-0W401, 23100-0W402, 23100-0W403, 23100-0W404
Specifications
Some listings may require the main stud to be changed
| B+ Stud Diameter & Thread Pitch (B+d) | M8x1.25 mm |
| B+ Thread Length (B+H) | 42.5 mm |
| Diode Amp Rating | 50 A |
| Diodes (Main) | 8 qty |
| Inside Diameter (I.D.1) | 39.5 mm |
| Outside Diameter (O.D.1) | 119.5 mm |
| Reg/Rec Combo | Yes |
| Unit Type | HITACHI |
| Voltage | 12 V |
Reference Information
UD18794ARRVideo/Publications
UD18794ARR LR1110735Add Your Number
