Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 19.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 4 qty |
| Length (L.1) | 163 mm |
| Mount Inside Length or Pad Mount C-C (C) | 37 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52.5 mm |
| Plug Code | PL_1100 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Yaris |
Reference Information
195.947.090.000 27060-0Y120 UD19340A J5112196Video/Publications
UD19340A 27060-0Y120 J5112196Add Your Number
