Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 179 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52.5 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 37 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Highlander 3.5 | 01.2017-12.2020 | |
| TOYOTA | Sienna 3.5 | 01.2017-12.2020 |
Reference Information
11889 195.301.180.260 ALN3548 ALT30658 MX1042110971 UD19342A A-80833 104211-0971 27060-0P420Video/Publications
104211-0971 UD19342A ALT30658 MX1042110971 27060-0P420 195.301.180.260 ALN3548 11889 A-80833Add Your Number
