Specifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 19 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 4 qty |
| Length (L.1) | 162 mm |
| Mount Inside Length or Pad Mount C-C (C) | 36.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 62.5 mm |
| Plug Code | PL_1100 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.33 | [1NR-FE] | 01.2012- |
| TOYOTA | Corolla 1.33 | [1NR-FE] | 01.2013- |
| TOYOTA | Verso S 1.33 | [1NR-FE] | 01.2010-12.2015 |
| TOYOTA | Yaris 1.33 | [1NR-FE] | 01.2011- |
Reference Information
104211-3022 104211-3021 104211-3340 195.975.100.260 104211-3020 CAL40393GS 209107 ALT2340CP 20132393OE 2706047260 27060-0Y160 27060-47150 AEK3819 DENDAN1093 LRA03819 DAN1093 UD90357A CGB-86929 195.975.100.050 104211-3090 28-6929 J5112181 DRA1094 27060-47260 27060-0Y130 ALT6458 553703RID 4357 2040393.1 LRA3819Video/Publications
104211-3020 104211-3021 104211-3022 104211-3090 104211-3340 20132393OE 2040393.1 209107 27060-0Y130 27060-0Y160 28-6929 4357 553703RID AEK3819 ALT2340CP CAL40393GS CGB-86929 DAN1093 DENDAN1093 DRA1094 J5112181 LRA03819 LRA3819 UD90357AAdd Your Number
