Specifications
| Amp | 85 A |
| Bottom Mounting Foot Width (B) | 17 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 12 mm |
| Length (L.1) | 176 mm |
| Mount Inside Length or Pad Mount C-C (C) | 72.5 mm |
| OEM Product | No |
| Plug Code | PL_9109 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Type | NO PULLEY |
| Unit Type | LUCAS/MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | JX100U 3.9 | [8045.25K] | 01.2002-12.2004 |
| CASE | JX70U 3.9 | [8045.06] | 01.2002-12.2004 |
| CASE | JX80U 3.9 | [8045.05] | 01.2002-12.2004 |
| CASE | JX90U 3.9 | [8045.25] | 01.2002-12.2004 |
| NEW HOLLAND | TL100 3.9 | [8045.25K] | 01.1998-12.2004 |
| NEW HOLLAND | TL70 3.9 | [8045.06] | 01.1998-12.2004 |
| NEW HOLLAND | TL80 3.9 | [8045.05] | 01.1998-12.2004 |
| NEW HOLLAND | TL90 3.9 | [8045.25] | 01.1998-12.2004 |
Reference Information
63220082010 UD19397A CGB-84894 A12MA0319A2 DA2463 166-15104 LRA02550 2030203.1 63321744010 705.504.085.770 500364130 MAN1043 12582N 63321822010 553261RI 705.504.085.050 PRAL438 47134024 28-4894 ALT12087 20104302OE AI-90294 EAA-211141 441953 500354130 LRA2550 A-4004 114384 CAL30203AS DRA1353 553261RIM 2311 20104302BN 90-19-2523 CAL30203GS ALTL438RR 63321744 ALTL438 2030203 63321822 290-20125 ALE4384Video/Publications
500354130 500364130 63220082010 63321744010 63321822010 LRA02550 MAN1043 UD19397A 705.504.085.770 553261RI 553261RIM CAL30203AS CAL30203GS 20104302BN 20104302OE DRA1353 DA2463 2030203.0 2030203.1 12582N ALTL438 ALTL438RR PRAL438 ALE4384 AI-90294 CGB-84894 114384 ALT12087 90-19-2523 2311 EAA-211141 28-4894 LRA2550 290-20125 A-4004 166-15104 705.504.085.050Add Your Number
