Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 14.5 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 198 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_2800 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 39 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | Citan 108 1.5 CDi | (415)[OM607.951] | 01.2012- |
| MERCEDES BENZ | Citan 109 1.5 CDi | (415)[OM607.951] | 01.2012- |
| MERCEDES BENZ | Citan 109 1.5 CDi Mixto | (415)[OM607.951] | 01.2012- |
| MERCEDES BENZ | Citan 111 1.5 CDi | (415)[OM607.951] | 01.2013- |
| MERCEDES BENZ | Citan 111 1.5 CDi Mixto | (415)[OM607.951] | 01.2013- |
| RENAULT | Kadjar 1.5 dCi 110 | [K9K646] | 01.2015- |
| RENAULT | Kadjar 1.5 dCi 110 | [K9K647] | 01.2015- |
| RENAULT | Kadjar 1.5 dCi 110 | [K9K648] | 01.2015- |
| RENAULT | Kadjar 1.5 dCi 110 | [K9K649] | 01.2015- |
Reference Information
A3552S 575.940.150.500 439808 575.940.150.004 AEK3752 23100-7239R A12VA0296AS 4893 0986084870 209265 2612716A LRA3752 CGB-11399 VAL439808 ALT00389 116355 CAL15575GS 4159063500 20355N PRAE541 89215972 553690RIV 2015575.1 57197 LRA03752 ALT14582 ALT175750 20179575OE ALV5431 ALT2151CP ALTE541 115431 DRA1399 986084870 FG15T056 55151082 A4159063500 DA2509 EAA-224212 23100-4554R 28-6862 UD90356AVideo/Publications
0986084870 115431 116355 2015575.1 20179575OE 20355N 209265 23100-4554R 23100-7239R 2612716A 28-6862 4159063500 439808 4893 553690RIV 57197 575.940.150.004 575.940.150.500 89215972 A4159063500 AEK3752 ALT14582 ALT175750 ALT2151CP ALTE541 ALV5431 CAL15575GS CGB-11399 DA2509 DRA1399 EAA-224212 FG15T056 LRA03752 LRA3752 PRAE541 UD90356A VAL439808Add Your Number
