Associated Numbers
0986CN0924 Bosch ruil
0986CR0924 Bosch ruil
0986UR0924 Bosch ruil
2011354 Ford show
21059 Lester
2161084 Ford
2188081 Ford show
2451723 Ford
288522 Elstock
40516 CEVAM
440810 Valeo
443011 Valeo
595946165 PSH
717619 Valeo A717619 A717619A
931971 EDR
AL2401N Bosch (USA)
AL2401X Bosch (USA)
DRA1971 Remy
GK2T10300AC Ford show
GK2T10300AD Ford show
GK2T10300AE Ford show
GK2T10300AF Ford
LRA04413 Lucas
TG15C206 Valeo
TG15C255 Valeo show
TG15C255SEL +line
GK2T-10300-AD, GK2T-10300-AE
MFR Series - Family Type AS7BP
Valeo TG15C255
Specifications
| Amp | 165 A |
| Bottom Mounting Foot Width (B) | 21 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 34 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 54 mm |
| Plug Code | PL_2305 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 48 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BJFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BJFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BKFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BKFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BLFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BLFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLF6] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLFS] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMF6] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMFS] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNF6] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNFS] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BJFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BJFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BKFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BKFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BLFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BLFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLF6] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLFS] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMF6] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMFS] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNF6] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNFS] | 01.2015- |
| FORD | Transit V363 2.0 EcoBlue | [BJFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BJFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BKFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BKFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BLFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BLFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLF6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLFS] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMF6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMFS] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNF6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNFS] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [BKRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [BLRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YMR6] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YMRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YNR6] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YNRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BJRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BKRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BLHA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BLRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YLR6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YLRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YMHA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YMR6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YNR6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | 01.2016- |
Reference Information
20179180OE 21059-OS 8EL015637-031 717619 TG15C285 440810 TG15C206 443011 2188081 A12VA0309A2 ALT14674 RMGK2T10300AE 0T000.A10.009 ALT2411CP ALV3467 2161084 ALT170810 89216822 21059N 555301RI 595.946.165.500 57793 726564 2451723 442666 DRA1971 28-8522 UD90769A A12VA0309 209588 AG2140 VAL443011 A726564A T000.A10.009 595.946.165.280 555301RIV ALT00921 A2031V RMGK2T-10300-AE 2015081.1 2011354 A3548S TG15C255 595.946.165.008 595.946.165.000 40516 LRA4413 GK2T-10300-AE CAL15081GS GK2T-10300-AF GK2T-10300-AC GK2T-10300-AD LRA04413Video/Publications
2011354 2015081.1 20179180OE 209588 21059-OS 2161084 2188081 28-8522 40516 555231RIV 595.946.165.000 595.946.165.500 ALT170810 ALV3467 CAL15081GS DRA1971 GK2T-10300-AC GK2T-10300-AD GK2T-10300-AE LRA04413 LRA4413 TG15C206 TG15C255 UD90769A VAL443011Add Your Number
