Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 16 mm |
| Length (L.1) | 245 mm |
| Mount Inside Length or Pad Mount C-C (C) | 82 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 50 mm |
| Outside Diameter (O.D.2) | 82 mm |
| Plug Code | PL_4510 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 49 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Panther 2.5 Grand Touring |
Reference Information
LR160-506 8976956020 ALH3468 UD19305AVideo/Publications
8976956020 LR160-506 UD19305A ALH3468Add Your Number
