Specifications
Amp | 110 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 6 qty |
Length (L.1) | 180 mm |
Mount Inside Length or Pad Mount C-C (C) | 82 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 62 mm |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 36 mm |
Pulley Type | SOLID |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Patrol 4.8 | [TB48DE] | 03.2000- |
Reference Information
UD21074A 23100-VC200 ALH0718 ALT3054 ALT32232 554765RI LR1110-718Video/Publications
