Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Grooves | 2 qty |
Groove Width (W.1) | 12.5 mm |
Length (L.1) | 187 mm |
Mount Inside Length or Pad Mount C-C (C) | 82 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 49 mm |
Outside Diameter (O.D.2) | 74 mm |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 38 mm |
Pulley Type | SOLID |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Patrol 4.2 | [TB42] | |
NISSAN | Patrol 4.5 | [TB45] |
Reference Information
UD21073A 165.560.100.415 23100-VB000 LR1100-708 ALT3051 ALH0709Video/Publications
UD21073A LR1100-708 ALH0709 165.560.100.415 23100-VB000Add Your Number
