Associated Numbers
410-54056 References: J&N Honda 31200HM7-003 31200HM7A41 Lester 18609 18638 Lucas TVS LSMU0048 SMU48 Mitsuba SM13449 PIC Picture ID 191-392 191-392A Wilson 71-26-18609 ARROWHEAD SMU0048 SMU0216Specifications
Check the O.1 (Mount hole C-C) measurement on your starter.
see 410-54066 for the 28.3 mm O.1 version
Length (L.1) | 197 mm |
Mount Hole Center - Center (O.1) | 23.3 mm |
Mount Hole Diameter (D.1) | 6 mm |
Mount Hole Diameter (D.2) | 6 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Rotation | ACW |
Unit Type | MITSUBA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | TRX 400 FW | 2002, 2003 | |
HONDA | TRX 450 ES | 1998, 1999, 2000, 2001 | |
HONDA | TRX 450 FE | 2002, 2003, 2004 | |
HONDA | TRX 450 FM | 2002, 2003, 2004 | |
HONDA | TRX 450 S | 1998, 1999, 2000, 2001 | |
HONDA | TRX 500 FE | 2005, 2006, 2007, 2008, 2009, 2010, 2011 | |
HONDA | TRX 500 FM | 2005, 2006, 2007, 2008, 2009, 2010, 2011 | |
HONDA | TRX 500 FPE | 2007, 2008, 2009, 2010, 2011 | |
HONDA | TRX 500 FPM | 2008, 2009, 2010, 2011 | |
HONDA | TRX 500 TM | 2005, 2006 |
