Associated Numbers
A3145 UD14862A ASPLList AEK3408 AUTOELECTRO 0986082500 BOSCH 114876 CARGO CAL15470 CASCO CAL15470GS 4832 CEVAM A9589 DIXIE 57340 EAI 286520 ELSTOCK 209190 ERA 210897 CA2072IR HC PARTS 6.3202.9 IKA ALV6105 KRAUF ALV6105DD LRA03408 LUCAS 0009063622 MERCEDES 0009068802 0131546802 013154680280 A0009063622 A0009068802 A0131546802 A01315468020080 A0131546802080 89215227 POWERMAX 555.590.180 PSH 20179074OE REAL 2015470 SANDO 2543406 VALEOList 2543406A VALEO 2618301 439653 439836 440238 440561 FG18S012 FG18S098 FG18S130 FGN18S012 FGN18S130 22721N WAI / TRANSPO ALT14466 WOODAUTO Remy Light Duty 11171 Valeo 439772 Wilson 90225706 References: Arrowhead AVA0154 Lester 11812 Lucas Mercedes PIC Picture ID 2085088 2614200 vxa909 Benz Bosch ruil 12090360 EuroTec 22721 241730 Cargo Elstock 543406 555590180 930568 EDR DRA0568 0009067900 0141543302 A0009067900 A0141543302 440328 FG18S077 L81550 ATL 28-6520 553695RIV 553993RIV A-9589 CAL15470AS CAL15470ES CAL15470OS CAL15470RS VXA909 ANV038GQ Mercedes-Benz 0986084590 115676 2015540 Sando 2618301A 555921180 618301 9068802 A2251981802 ALT00034SA Electrolog show FGN18S130RR RNL RNLFGN18S130 Parts CA2072 IAT A11812 Industry 000-906-880-02 208-5187 New Reman anv038gq Voltux V2-11812Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Diameter (D.1) | 9.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 9.5 mm |
| Diameter (D.4) | 9.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 49.5 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 32 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | C 220 2.2 CDi | (W204)[OM651.913] | 01.2010- |
| MERCEDES BENZ | C 250 2.2 CDi | (W204)[OM651.911] | 01.2008- |
| MERCEDES BENZ | C 300 3.5 | (W204)[OM651.911] | 01.2008- |
| MERCEDES BENZ | C 300 3.5 4-Matic | (W204)[M276.957] | 01.2011- |
| MERCEDES BENZ | C 350 3.5 | (W204)[M276.957] | 01.2011- |
| MERCEDES BENZ | C 350 3.5 4-Matic | (W204)[M276.957] | 01.2011- |
| MERCEDES BENZ | C 350 3.5 CGI | (W204)[M276.957] | 01.2011- |
| MERCEDES BENZ | CLS 220 2.2 CDi BlueTEC | (W218)[M276.957] | 01.2011- |
| MERCEDES BENZ | CLS 250 2.2 CDi | (W218)[OM651.924] | 01.2014- |
| MERCEDES BENZ | CLS 250 2.2 CDi BlueTEC | (W218)[OM651.924] | 01.2011- |
| MERCEDES BENZ | CLS 250 2.2 CDi BlueTEC 4-Matic | (W218)[OM651.924] | 01.2014- |
| MERCEDES BENZ | E 200 2.2 CDi BlueTEC | (W212)[OM651.924] | 01.2014- |
| MERCEDES BENZ | E 220 2.2 CDi | (W212)[OM651.925] | 01.2009- |
| MERCEDES BENZ | E 220 2.2 CDi BlueTEC | (W212)[OM651.924] | 01.2009- |
| MERCEDES BENZ | E 250 2.2 CDi | (W212)[OM651.924] | 01.2009- |
| MERCEDES BENZ | E 250 2.2 CDi BlueTEC | (W212)[OM651.924] | 01.2009- |
| MERCEDES BENZ | E 300 3.5 | (W207)[OM651.924] | 01.2009- |
| MERCEDES BENZ | E 350 3.5 | (W207)[M276.957] | 01.2011- |
| MERCEDES BENZ | E 350 3.5 4-Matic | (W207)[M276.957] | 01.2011- |
| MERCEDES BENZ | GLE 250 2.1 d | (W166)[M276.957] | 01.2013- |
| MERCEDES BENZ | GLK 200 2.2 CDi | (W204)[OM651.960] | 01.2015- |
| MERCEDES BENZ | GLK 220 2.2 CDi | (W204)[OM651.913] | 01.2010- |
| MERCEDES BENZ | ML 250 2.2 CDi BlueTEC 4-Matic | (W166)[OM651.916] | 01.2009- |
| MERCEDES BENZ | ML 300 3.5 4-Matic | (W166)[OM651.960] | 01.2011- |
| MERCEDES BENZ | ML 350 3.5 4-Matic | (W166)[M276.955] | 01.2014- |
| MERCEDES BENZ | SL 350 3.5 | (W231)[M276.955] | 01.2011- |
| MERCEDES BENZ | SL 400 3.0 | (W231)[M276.954] | 01.2013- |
| MERCEDES BENZ | SLC 250 2.1 d | (W172)[M276.825] | 01.2014- |
| MERCEDES BENZ | SLC 250 2.1 D | (W172)[M276.825] | 01.2014- |
| MERCEDES BENZ | SLK 250 2.2 CDi | (W172)[OM651.980] | 01.2016- |
| MERCEDES BENZ | SLK 350 3.5 | (W172)[M651.980] | 01.2012- |
| MERCEDES BENZ | Sprinter 210 2.1 CDi | (W906)[M276.956] | 01.2011- |
| MERCEDES BENZ | Sprinter 211 2.1 CDi | (W906)[OM651.955] | 01.2009- |
| MERCEDES BENZ | Sprinter 213 2.1 CDi | (W906)[OM651.955] | 01.2016- |
| MERCEDES BENZ | Sprinter 214 2.1 CDi | (W906)[OM651.956] | 01.2009- |
| MERCEDES BENZ | Sprinter 216 2.1 CDi | (W906)[OM651.955] | 01.2016- |
| MERCEDES BENZ | Sprinter 310 2.1 CDi | (W906)[OM651.957] | 01.2009- |
| MERCEDES BENZ | Sprinter 311 2.1 CDi | (W906)[OM651.955] | 01.2009- |
| MERCEDES BENZ | Sprinter 313 2.1 CDi | (W906)[OM651.955] | 01.2016- |
| MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (W906)[OM651.956] | 01.2012-12.2016 |
| MERCEDES BENZ | Sprinter 314 2.1 CDi | (W906)[OM651.956] | 01.2009- |
| MERCEDES BENZ | Sprinter 316 2.1 CDi | (W906)[OM651.955] | 01.2016- |
| MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (W906)[OM651.957] | 01.2009- |
| MERCEDES BENZ | Sprinter 413 2.1 CDi | (W906)[OM651.957] | 01.2011- |
| MERCEDES BENZ | Sprinter 416 2.1 CDi | (W906)[OM651.955] | 01.2009-12.2015 |
| MERCEDES BENZ | Sprinter 416 2.1 CDi | (W906)[OM651.956] | 01.2009-12.2016 |
| MERCEDES BENZ | Sprinter 510 2.1 CDi | (W906)[OM651.957] | 01.2009- |
| MERCEDES BENZ | Sprinter 511 2.1 CDi | (W906)[OM651.955] | 01.2009- |
| MERCEDES BENZ | Sprinter 513 2.1 CDi | (W906)[OM651.955] | 01.2016- |
| MERCEDES BENZ | Sprinter 513 2.1 CDi 4x4 | (W906)[OM651.956] | 01.2009- |
| MERCEDES BENZ | Sprinter 514 2.1 CDi | (W906)[OM651.956] | 01.2009- |
| MERCEDES BENZ | Sprinter 516 2.1 CDi | (W906)[OM651.955] | 01.2016- |
| MERCEDES BENZ | Sprinter 516 2.1 CDi 4x4 | (W906)[OM651.957] | 01.2009- |
| MERCEDES BENZ | Viano 2.0 CDi | (W639)[OM651.957] | 01.2009- |
| MERCEDES BENZ | Viano 2.0 CDi 4-Matic | (W639)[OM651.940] | 01.2010- |
| MERCEDES BENZ | Vito 110 2.2 CDi | (W639)[OM651.940] | 01.2010- |
| MERCEDES BENZ | Vito 113 2.2 CDi | (W639)[OM651.940] | 01.2010- |
| MERCEDES BENZ | Vito 113 2.2 CDi 4x4 | (W639)[OM651.940] | 01.2010- |
| MERCEDES BENZ | Vito 116 2.2 CDi | (W639)[OM651.940] | 01.2010- |
| MERCEDES BENZ | Vito 116 2.2 CDi 4x4 | (W639)[OM651.940] | 01.2010- |
Alternatives >>>
A3436S - Has Solid Pulley, can purchase AFP3021(INA) to convert
A3145PR Remanufactured Alternator
Reference Information
0009063622 0009068802 0131546802 013154680280 0986082500 114876 2015470 20179074OE 209190 210897 22721N 2543406 2543406A 2618301 28-6520 439653 439836 440238 440561 4832 553695RIV 553993RIV 555.590.180 57340 6.3202.9 89215227 A-9589 A0009063622 A0009068802 A0131546802 A01315468020080 A0131546802080 AEK3408 ALT14466 ALTF181 ALTL632 ALV6105 ALV6105DD CA2072IR CAL15470 CAL15470AS CAL15470ES CAL15470GS CAL15470OS CAL15470RS FG18S012 FG18S098 FG18S130 FGN18S012 FGN18S130 LRA03408 LRA3408 RNLFG18S012 UD14862AAdd Your Number
