Associated Numbers
SS5178P AS-PL
940113050410 MAGNETI MARELLI
AME0410 MAGNETI MARELLI
SB591 MITSUBISHI
ZM1797 ZM
M003T10881 MITSUBISHI
M3T10881 MITSUBISHI
Specifications
Product features:
| Voltage [ V ] | 12 |
| I.D.1 [ mm ] | 22.50 |
| O.D.1 [ mm ] | 51.50 |
| O.D.2 [ mm ] | 45.50 |
| L.1 [ mm ] | 79.00 |
| B+ [ mm ] | M8x1.25 |
| L.B+ [ mm ] | 15.00 |
| Coil bolt [ mm ] | M8x1.25 |
| L.Coil bolt [ mm ] | 14.00 |
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 14 mm |
| Inside Diameter (I.D.1) | 22.5 mm |
| L.B+ | 15 mm |
| Length (L.1) | 79 mm |
| Outside Diameter (O.D.1) | 51.5 mm |
| Outside Diameter (O.D.2) | 45.5 mm |
| Type | Solenoid |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
AME0410 9.40113E+11 SS5178P 227118 SB591 ZM1797Video/Publications
AME0410 940113050410 M003T10881 SS5178P M3T10881 227118 SB591 ZM1797Add Your Number
