Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 19.5 mm |
Inside Diameter (I.D.1) | 22.5 mm |
L.B+ | 32 mm |
Length (L.1) | 76 mm |
Outside Diameter (O.D.1) | 52 mm |
Outside Diameter (O.D.2) | 44 mm |
Type | Solenoid |
Unit Type | PRESTOLITE |
Voltage | 12 V |
Reference Information
66-608 SS9223P F042011151 SSP0385 ZM5485 35640955 K01182 SNLS385 054.000.406.150 SOL9704Video/Publications
35261135 35259640 66-608 35259430 35259450 ZM5485 K01182 SS9223P F042011151 SSP0385 35640955 SNLS385 054.000.406.150Add Your Number
