Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 19 mm |
Inside Diameter (I.D.1) | 22 mm |
L.B+ | 21.5 mm |
Length (L.1) | 64 mm |
Outside Diameter (O.D.1) | 52 mm |
Outside Diameter (O.D.2) | 44 mm |
Type | Solenoid |
Unit Type | PRESTOLITE |
Voltage | 12 V |
Reference Information
SS9212P K01340 227167 35640920 ZM2484 SOL9739 230920Video/Publications
SS9212P K01340 35258790 227167 35640920 ZM2484 35258850 230920Add Your Number
