Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 13 mm |
L.B+ | 16.5 mm |
Length (L.1) | 91 mm |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 51 mm |
Type | Solenoid |
Unit Type | BOSCH |
Voltage | 12 V |
Reference Information
SS9138P 9330081010 227418 ZM523Video/Publications
SS9138P 9000082006 9330081010 9000082015 227418 9000083016 9000083017 ZM523Add Your Number
