Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 24 mm |
| Inside Diameter (I.D.1) | 27.5 mm |
| L.B+ | 25.5 mm |
| Length (L.1) | 112.5 mm |
| Outside Diameter (O.D.1) | 55.5 mm |
| Outside Diameter (O.D.2) | 56.5 mm |
| Type | Solenoid |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Reference Information
UD46956SSVideo/Publications
M8T60171 S5300S UD46956SS M008T60171Add Your Number
