Associated Numbers
M8T71071
M8T71071zt
Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 14 mm |
| Inside Diameter (I.D.1) | 25.2 mm |
| L.B+ | 14.8 mm |
| Length (L.1) | 75.5 mm |
| Outside Diameter (O.D.1) | 51.4 mm |
| Outside Diameter (O.D.2) | 45.3 mm |
| Type | Solenoid |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
227399 UD14492SS(ZM) F042010391 MITM371XA0273 SND12458 M371XA0273 UD16366SS SSO35104 MD618972 ZM4993 SOL5050 CSO35104Video/Publications
UD14492SS(ZM) M002T87971 MITM371XA0273 M002T87871 M2T84071 ME701462 227399 F042010391 SND12458 SSO35104 M008T75071 M2T87871 M2T87971 CSO35104 M002T84071 M002T84171 M002T84571 M2T87171 M2T87371 M371XA0273 M8T75071 M2T84571 M2T84171 UD16366SS MD618972 ZM4993 M002T87171 M002T87371Add Your Number
