Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 14.5 mm |
Inside Diameter (I.D.1) | 25.2 mm |
L.B+ | 15.2 mm |
Length (L.1) | 75.8 mm |
Outside Diameter (O.D.1) | 51.5 mm |
Outside Diameter (O.D.2) | 45.4 mm |
Type | Solenoid |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Reference Information
UD15139SS UD16411SS ZM6695 237498 66-8382 SND13031 UD12512SS UD14501SS(ZM) 227625 66-8384Video/Publications
ZM6695 237498 66-8382 UD12512SS UD14501SS(ZM) 227625 66-8384 M1T84381 56041012AD M1T84382 UD15139SS UD16411SS SND13031 M1T84381ZC M1T84382ZC 56041012ABAdd Your Number
