Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 15 mm |
| Inside Diameter (I.D.1) | 22 mm |
| L.B+ | 16 mm |
| Length (L.1) | 73 mm |
| Outside Diameter (O.D.1) | 52 mm |
| Outside Diameter (O.D.2) | 44 mm |
| Type | Solenoid |
| Unit Type | HITACHI |
| Voltage | 12 V |
Reference Information
1987001012 ZM680 23343-N3300 23343-N3301 131800 227504 SSO20105.0 2108-4823 227116 81016132 227772 31204-634-005 SND1155 X211457001 UD15910SS CSO20105AS 054.000.347.086 X211487004 SS2066P 2114-87004 2114-87002 2114-57604 227642 20345501BN TOJ103 2114-57001 2114-97503 E8010 2114-97004 SSH8105Video/Publications
1987001012 S114173 S114230 ZM680 23343-N3300 23343-N3301 131800 SSO20105.0 227504 2108-4823 81016132 227116 S114254A 227772 054.000.347 31204-634-005 S114353 SND1155 X211457001 S114173F S114235 UD15910SS CSO20105AS 054.000.347.086 S10885 S114229E X211487004 S114229F S114235A SS2066P 2114-87004 S10886 2114-87002 2114-57604 227642 20345501BN S10891 TOJ103 2114-57001 2114-97503 E8010 S114170B 2114-97004 S114172E SSH8105Add Your Number
