Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 13.6 mm |
Inside Diameter (I.D.1) | 22.3 mm |
L.B+ | 12.5 mm |
Length (L.1) | 60.2 mm |
Outside Diameter (O.D.1) | 52.2 mm |
Outside Diameter (O.D.2) | 44.4 mm |
Type | Solenoid |
Unit Type | HITACHI |
Voltage | 12 V |
Reference Information
66-8135 UD16242SS 2114-77507 ZM2719 2114-77506 2114-77607 SSH5784 9.40113E+11 1016831 227194 2114-T7306 SSH9784 2114-T7106 23343-80W01 SND12192 23343-80W00 81016831 2114-27608 CQ2030624 2114-17612 AME0445 UD00300SS 2114-97604 2114-T7160 SSH6784 UD14458SS(ZM) 139784Video/Publications
66-8135 S114-806A UD16242SS 2114-77507 ZM2719 2114-77506 940113050445 2114-77607 SSH5784 1016831 2114-T7306 227194 SSH9784 2114-T7106 23343-80W01 SND12192 23343-80W00 S114-701C 2114-27608 81016831 S114-701A CQ2030624 2114-17612 AME0445 UD00300SS 2114-97604 2114-T7160 SSH6784 UD14458SS(ZM) 139784Add Your Number
