Specifications
B+ Stud Diameter & Thread Pitch (B+) | UNC 1/2-13 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | UNC 1/4-20 mm |
Coil Bolt Length | 10 mm |
Inside Diameter (I.D.1) | 33 mm |
L.B+ | 35 mm |
Length (L.1) | 121.5 mm |
Outside Diameter (O.D.1) | 68.5 mm |
Outside Diameter (O.D.2) | 76 mm |
Type | Solenoid |
Unit Type | DELCO |
Voltage | 12 V |
Reference Information
1115617 E6003 66-138-1 AME0042 SOL2745 9.40113E+11 D924A SSD1925 231925 054.000.474 227343 60-01-3642 ZM467 1011425 SND12093 6601-3715Video/Publications
1993971 1115617 940113050042 1993866 E6003 66-138-1 AME0042 D924A SSD1925 054.000.474 231925 227343 60-01-3642 ZM467 1011425 SND12093 6601-3715Add Your Number
