Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 12 mm |
Inside Diameter (I.D.1) | 22 mm |
L.B+ | 16 mm |
Length (L.1) | 90.5 mm |
Outside Diameter (O.D.1) | 51.5 mm |
Outside Diameter (O.D.2) | 57 mm |
Type | Solenoid |
Unit Type | DELCO |
Voltage | 12 V |
Reference Information
CQ2030720 SOL2714 3471725 1015673 DR904 66-180 227466 3471929 SNLS-157 3471979 ZM555 131273 UD15688SS SND1266Video/Publications
3471155 CQ2030720 3471725 1015673 DR904 3471169 66-180 227466 3471929 SNLS-157 3471979 ZM555 131273 UD15688SS SND1266Add Your Number
