Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
| Coil Bolt Length | 16.5 mm |
| Inside Diameter (I.D.1) | 30 mm |
| L.B+ | 24 mm |
| Length (L.1) | 82.5 mm |
| Outside Diameter (O.D.1) | 61 mm |
| Outside Diameter (O.D.2) | 53.5 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Reference Information
66-9107-1 UD43921SS CGB-645A 66-9107 CSO10621AS 331402201 E3600 6660-6222-2 333138 20301126BN 9.40113E+11 1523410 6660-6222 19024451 ELE0060 227592 CQ2030006 A0001523410 CGB-1645A AME0186 130303Z 331402510 130303 UD15164SS 333664 BOS0331402010 331402010 60-15-6572 SS0004 SSO10621.0 16.905.395 SOL1063 81011356 SND1148 UD15886SS ZM645 SNLS-281Video/Publications
940113050186 0001368055 66-9107-1 66-9107 1368055 E3600 6660-6222-2 333138 1360037 0331402201 6660-6222 19024451 SSO10621 227592 0001368028 CSO10621 1360056 0001360022 0001368024 CQ2030006 A0001523410 1368024 AME0186 130303Z 130303 UD15164SS 333664 BOS0331402010 60-15-6572 SS0004 UD807003(BOSCH)SS 0001360037 0001523410 0331402510 0331402010 1011356 16.905.395 81011356 1368028 SND1148 UD15886SS UD14365SS(ZM) 1360022 ZM645 0001360056Add Your Number
