Specifications
Inside Diameter (I.D.1) | 12 mm |
Length (L.1) | 61.5 mm |
Length (L.2) | 14.6 mm |
No./Splines | 12 qty |
No./Teeth | 11 qty |
Outside Diameter (O.D.1) | 46.5 mm |
Outside Diameter (O.D.2) | 29.2 mm |
Rotation | ACW |
Type | Drive |
Unit Type | ISKRA / LETRIKA |
Reference Information
AMB0382 ZN1088 1088 2265 49-52-84 16.900.035 060.000.769.830 1.01.1088.0 UD17854SD 9.40113E+11 SD9218P SDV32184 SDI1088Video/Publications
ZN1088 49-52-84 0001354016 1354012 0001354017 16.900.035 225517 1354017 0001354012 1354016 1.01.1088.0 0001354011 UD17854SD 1354011 SD9218P SDI1088Add Your Number
