Specifications
Inside Diameter (I.D.1) | 12.5 mm |
Length (L.1) | 82.5 mm |
Length (L.2) | 37.2 mm |
No./Splines | 10 qty |
No./Teeth | 9 qty |
Outside Diameter (O.D.1) | 46.5 mm |
Outside Diameter (O.D.2) | 34.4 mm |
Rotation | CW |
Type | Drive |
Unit Type | DENSO |
Reference Information
028300-1388 028300-1389 1.01.0343.0 028300-1386 028300-1387 ZN0343 225139 DRV6076 1014743 343 UD17655SD 028300-1380 5446-0806 028300-1381 028300-3590 06-014 6118 028300-1390 SDV32681 028300-1384 028300-1385 028300-1382 54-8240 028300-1383Video/Publications
028300-1388 028300-1389 1.01.0343.0 280003611 028300-1386 280003610 028300-1387 ZN0343 2800033610 0280003610 0280003611 280007480 0343 UD17655SD 028300-1380 5446-0806 028300-1381 028300-1384 028300-1385 028300-1382 54-8240 028300-1383 0280003360 0280007481 225139 280003360 1014743 280007481 0280007480 028300-3590 06-014 028300-1390 6118 SDV32681Add Your Number
