Specifications
Height (H.1) | 32.2 mm |
Inside Diameter (I.D.1) | 18 mm |
No./Splines | 26 qty |
No./Teeth | 12 qty |
Outside Diameter (O.D.1) | 43.5 mm |
Rotation | CW |
Type | Pinion |
Unit Type | MITSUBISHI |
Reference Information
SPM3966 GEAR5028 UD41257SDVideo/Publications
M009T62671 S5301S M9T84171 S5064 SPM3966 M9T65971 M9T80871 M9T61971 S5147 UD41257SD S5447S S5326S S5229 S5207 M9T50471 19011504 S5227 S5192 S5077 S5078 S5174 M9T83071 S5443S M9T62671 M9T83671 M9T20171 M9T83771 S1018 SD5054 M9T72271 S5058 M009T61971Add Your Number
