Specifications
Inside Diameter (I.D.1) | 12 mm |
Length (L.1) | 56.5 mm |
Length (L.2) | 27.4 mm |
No./Splines | 9 qty |
No./Teeth | 10 qty |
Outside Diameter (O.D.1) | 46.5 mm |
Outside Diameter (O.D.2) | 26.8 mm |
Rotation | ACW |
Type | Drive |
Unit Type | LUCAS |
Reference Information
81013609 1.01.0822.0 SDV3198 SDL3296 ZN0822 225363 TMB174 822 UD17781SD 133296 1013609 54292929 SD4109PVideo/Publications
1.01.0822.0 81013609 SDV3198 SDL3296 26811A 26812A ZN0822 26812D 26702 26717A 225363 26702K 26702E TMB174 UD17781SD 1013609 133296 54292929 SD4109P 0822Add Your Number
