Specifications
| Inside Diameter (I.D.1) | 14 mm |
| Length (L.1) | 69.5 mm |
| Length (L.2) | 18.7 mm |
| No./Splines | 12 qty |
| No./Teeth | 9 qty |
| Outside Diameter (O.D.1) | 60 mm |
| Outside Diameter (O.D.2) | 34.5 mm |
| Rotation | CW |
| Type | Drive |
| Unit Type | HITACHI |
Reference Information
ZN0684 DRV3108 54-8117-1 UD17738SD 2120-15501 684 9.40113E+11 1014564 1.01.0684.0 SDV38561 54-8117 133361 SD2079P 61-25-14161 225292 2130-9500 5440-1801Video/Publications
S1332A ZN0684 2330079601 54-8117-1 UD17738SD 2120-15501 940113020215 S1329 0684 1.01.0684.0 1014564 SDV38561 54-8117 S1262 5811000571 133361 SD2079P S1332 61-25-14161 5811000740 225292 2130-9500 5440-1801Add Your Number
