Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 179 mm |
Mount Hole Center - Center (O.1) | 94 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 14 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | HYUNDAI / KIA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | i20 1.4 | [G4LC] | 07.2018- |
HYUNDAI | i30 1.4 T-GDi | [G4LD] | 03.2017- |
HYUNDAI | i30 1.4 T-GDi | [G4LD] | 06.2017- |
HYUNDAI | i30 1.4 T-GDi | [G4LD] | 11.2016- |
KIA | Ceed 1.4 T-GDi | [G4LD] | 03.2018- |
KIA | Ceed 1.4 T-GDi | [G4LD] | 04.2018- |
KIA | Proceed 1.4 T-GDi | [G4LD] | 10.2018- |
KIA | Rio 1.4 | [G4LC] | 01.2017- |
KIA | Stonic 1.4 CVVT | [G4LC] | 07.2017- |
Reference Information
36100-03751 6046123.1 36100-03853 UD18557S MAV481230 CST46123GS S-1550 STD5881 RAS32424 20460321OE 25-5406 DRS1313 LRS04244 3610003851 LRS4244 3610004900 8000843Video/Publications
25-5406 36100-03751 36100-03853 8000843 DRS1313 LRS04244 LRS4244 RAS32424 S-1550 STD5881 UD18557SAdd Your Number
