Specifications
| Kilowatt | 1.6 kW |
| Length (L.1) | 245 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 33 mm |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ACURA | ILX 2.4 | 01.2013-12.2015 | |
| HONDA | Civic 2.4 | 01.2012-12.2015 | |
| HONDA | Crosstour 2.4 | 01.2012-12.2015 | |
| HONDA | CR-V 2.4 | 01.2012-12.2014 |
Reference Information
S9408S 91-26-2169 120.031.092.190 CST33170AS STR5909 20467071BN 6033170 UD20601S 19280N SM740-17 31200-R5A-A02 31200-R5A-A01 SM740-02 STU7407 31200-RX0-A01 31200-RX0-A02 S-80545Video/Publications
19280N 31200-R5A-A01 31200-R5A-A02 31200-RX0-A01 31200-RX0-A02 91-26-2169 S-80545 SM740-02 SM740-17 STU7407 UD20601SAdd Your Number
