Associated Numbers
19264/19159
OEM 31200-R1A-A01 31200-R1A-A02
31200-R1A-A11 31200-R1A-A12
SM74001 SM74014 SM74004
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 218 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 34 mm |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ACURA | ILX 2.0 | 01.2013-12.2015 | |
| HONDA | Civic 1.8 | 01.2012-12.2015 | |
| HONDA | HR-V 1.8 | 01.2016-12.2016 |
Reference Information
31200-R1A-A01 31200-R1A-A12 91-26-2166 31200-R1A-A02 STR5908 0000986UR1612 31200-RIA-A11 0986UR1612 STU7401 UD20600S 31200-R0A-004 SM74004 SM740-14 19264NVideo/Publications
0986UR1612 19264N 31200-R0A-004 31200-R1A-A01 31200-R1A-A02 31200-R1A-A12 31200-RIA-A11 91-26-2166 SM740-14 SM74004 STU7401 UD20600SAdd Your Number
