Specifications
| Kilowatt | 7.8 kW |
| Length (L.1) | 317 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| Mount Hole Diameter (C.2) | 14 mm |
| Mount Hole Diameter (C.3) | 14 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | CUMMINS |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | Various Models |
Reference Information
3958033 91-29-5656 6040630.1 DSN2029 STR6205 S-8920 428000-0060 STR70347 4280800060 701.501.103 CST40630GS 254750C S9403S STR70342 20432036OE 641.515.103 246-30214 246-30234 UD90482S TG4280800060 CST40630AS DENDSN2002 6040630 12022101 DSN2002 254750 190-30144 20432036BN 19097N 254751CVideo/Publications
12022101 190-30144 19097N 20432036BN 20432036OE 246-30214 246-30234 254750 254750C 254751C 3958033 428000-0060 4280800060 6040630.0 6040630.1 641.515.103 701.501.103 91-29-5656 CST40630AS CST40630GS DENDSN2002 DSN2029 S-8920 STR70342 STR70347 TG4280800060 UD90482S S9403SAdd Your Number
