Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
FORD
Price:
NZ$ 278.98 including GST
NZ$ 242.59 excluding GST
or four payments of $69.75
with
Learn More
UOM:
each
Product Code:
S9396S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
98AB-11000-ECSpecifications
| Kilowatt | 1.50 kW |
| Length (L.1) | 226 mm |
| Mount Hole Center - Center (O.1) | 66 mm |
| Mount Hole Center - Center (O.2) | 103 mm |
| Mount Hole Center - Center (O.3) | 66 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 4.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Focus 2.0 i 16V | [EDDB] | 01.1998-12.2004 |
| FORD | Focus 2.0 i 16V | [EDDC] | 01.1998-12.2004 |
| FORD | Focus 2.0 i 16V | [EDDD] | 01.1998-12.2004 |
| FORD | Focus 2.0 i 16V | [EDDF] | 01.1998-12.2004 |
| FORD | FOCUS I Saloon (DFW) 2.0 16V | EDDB | 02.1999-11.2004 |
| FORD | FOCUS I Saloon (DFW) 2.0 16V | EDDC | 02.1999-11.2004 |
| FORD | FOCUS I Saloon (DFW) 2.0 16V | EDDD | 02.1999-11.2004 |
| FORD | FOCUS I Saloon (DFW) 2.0 16V | EDDF | 02.1999-11.2004 |
| FORD | FOCUS I Turnier (DNW) 2.0 16V | EDDB | 02.1999-11.2004 |
| FORD | FOCUS I Turnier (DNW) 2.0 16V | EDDC | 02.1999-11.2004 |
| FORD | FOCUS I Turnier (DNW) 2.0 16V | EDDD | 02.1999-11.2004 |
| FORD | FOCUS I Turnier (DNW) 2.0 16V | EDDF | 02.1999-11.2004 |
Reference Information
| 020834 | DA SILVA |
| 06-10191-SX | STELLOX |
| 10440956 | ALANKO |
| 1061272 | FORD |
| 11090236 | EUROTEC |
| 220407 | ERA |
| 25-4349 | ELSTOCK |
| 3122957 | HENKEL PARTS |
| 319083102 | DRI |
| 3912 | CEVAM |
| 410-14051 | J&N |
| 438388 | VALEO |
| 458860 | VALEO |
| 590.578.103.020 | WAI |
| 590.578.103.440 | WAI |
| 6655 | LESTER |
| 6655N | WAI |
| 6655R | WAI |
| 8080368 | FRIESEN |
| 88214839 | POWERMAX |
| 91-02-5894 | WILSON |
| 91-02-5894N | WILSON |
| 98AB-11000-EC | FORD |
| AEY2677 | AUTOELECTRO |
| JD020834 | DA SILVA |
| LRS02677 | LUCAS |
| LRS2677 | LUCAS |
| S134.542 | WAI |
| S-2106 | DIXIE |
| S9396S | AS-PL |
| SFD0090 | ARROWHEAD |
| ST01842 | TMI |
| STF4407 | KRAUF |
| STR00287 | ELECTROLOG |
| TT16278 | TESLA TECHNICS |
| TTST001359 | TURBO-TEC |
| UD20620S | AS-PL |
| YS4Z-11002-EA | FORD |
| YS4Z-11002-EARM | FORD |
| YS4Z-11002-EB | FORD |
| YS4Z-11002-EBRM | FORD |
Video/Publications
