Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 226 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 80 mm |
| Mount Hole Center - Center (O.3) | 133 mm |
| Mount Hole Diameter (C.1) | 10 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 10 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 14 mm |
| Rotation | CW |
| Spigot Diameter (A) | 103 mm |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Mustang 2.3 LX | 01.1991-01.1993 | |
| FORD | Mustang 2.3 Turbo | 01.1980- | |
| FORD | Mustang 2.3 Turbo | 01.1981- | |
| FORD | Mustang 2.3 Turbo | 01.1982- | |
| FORD | Ranger 2.3 | 01.1991-01.1996 | |
| FORD | Ranger 2.3 | 01.1997-01.1997 | |
| FORD | Ranger 2.3 | 10.1990-12.1995 | |
| FORD | Ranger 2.3 Super | 01.1992-01.1997 | |
| MAZDA | B2300 2.3 | 01.1994-01.1997 |
Reference Information
880.544.103 F1TZ11002A STR8900 F17UAB STF3222 STR80036 F17U-11000-AB 91-02-5863 F17U11000AB ZZMO-18-400 SA785 113222 UD20608S LRS1746 LRS01746 339173 150-10110 ZZM018400 3238R 3238N 25-3311 254478 F87UAA F87U11000A1A 91-02-5863N F87U11002AA ZZP118400 F87U11000A1B F87U11000AAVideo/Publications
113222 150-10110 25-3311 254478 3238N 3238R 880.544.103 91-02-5863 91-02-5863N F17U-11000-AB F17U11000AB F17UAB F1TZ11002A F87U11000A1A F87U11000A1B F87U11000AA F87U11002AA F87UAA LRS01746 LRS1746 STF3222 STR80036 UD20608S ZZM018400 ZZP118400Add Your Number
